The "Exhauster Systems" , the heart of the gas handling process. They are essentially industrial-grade fans or compressors, but their role is far more complex than just moving gases. Robust and efficient gas handling systems designed to manage and extract process gases in coke oven and by-product plants.
Competitive advantages and design features:
- The exhausters are single-cylinder, two-stage units with suction on one side.
- The system delivers a powerful flow, with a capacity between 450 and 1380 m³/min.
- The exhauster’s case is constructed from cast iron and can be split both horizontally and vertically.
- The gas flow path is formed by two impellers on a single shaft, along with diffusers and guiding vanes, while labyrinth seals separate the compression stages. The unit is driven by an asynchronous motor.
- These exhausters come with a shaft-turning gear as a standard feature.
Our exhauster systems are a testament to our commitment to providing high-quality, reliable solutions for the steel industry. With installations across major steel plants, we continue to support industrial operations with equipment that meets the highest standards of performance and durability.
KEY FEATURES
- Capacity: 450–1380 m³/min
- Pressure: 2410–3760 mm water column
- Power Consumption: 270–950 kW
- Rotor Speed: 3906–4760 rpm
- Engine Power: 800–1250 kW
- Voltage: 6000 V
- Coolant Flow: 30–44.7 m³/h
DESIGN & CONSTRUCTION
- Casing: Durable cast iron with both horizontal and vertical splits for ease of maintenance conforming to various standards.
- Impellers: Two impellers mounted on a single shaft, optimized with diffusers and guiding vanes for efficient gas flow.
- Sealing: Labyrinth seals between compression stages to prevent gas leakage.
- Drive: Powered by HT motors ensuring consistent performance.
- Suction & Delivery: Downward-turned nozzles facilitate smooth gas intake and discharge.
APPLICATIONS
- Steel Plants: Ideal for facilities like Vizag Steel Plant, Rourkela Steel Plant, and Durgapur Steel Plant.
- Coke Production Units: Efficiently handles gas extraction and conveyance in coke-making processes.
